JAPAN HSR-BM Caged Ball LM Guides THK HSR20BM BLOCK HSR20BM2QZ+1240L-HSR20BM2QZC0M+1240LM-HSR20BM2C1+1240LP Linear Guides
JAPAN HSR-BM Caged Ball LM Guides THK HSR20BM BLOCK HSR20BM2QZ+1240L-HSR20BM2QZC0M+1240LM-HSR20BM2C1+1240LP Linear Guides
THK HSR20BM Linear Motion Ball LM Guide Rail and Slide Block Linear bearing
Balls roll in four rows of raceways precision-ground on an LM rail and an LM block, and ball cages and
endplates incorporated in the LM block allow the balls to circulate.
Each row of balls is placed at a contact angle of 45°so that the rated loads applied to the LM block are
uniform in the four directions (radial, reverse-radial and lateral directions), enabling the LM Guide to be
used in all orientations. In addition, the LM block can receive a well-balanced preload, increasing the
rigidity in the four directions while maintaining a constant, low friction coefficient. With the low
sectional height and the high rigidity design of the LM block, SHS achieves highly accurate and stable
linear motion.
endplates incorporated in the LM block allow the balls to circulate.
Each row of balls is placed at a contact angle of 45°so that the rated loads applied to the LM block are
uniform in the four directions (radial, reverse-radial and lateral directions), enabling the LM Guide to be
used in all orientations. In addition, the LM block can receive a well-balanced preload, increasing the
rigidity in the four directions while maintaining a constant, low friction coefficient. With the low
sectional height and the high rigidity design of the LM block, SHS achieves highly accurate and stable
linear motion.
Product Description
|
||||
Type
|
THK Linear Guideway Block
|
|||
Model Number
|
HSR20BM
|
|||
Material
|
Bearing Steel
|
|||
Brand
|
THK
|
|||
Condition
|
New Original
|
|||
Features
|
High Speed, Long life
|
|||
Block weight (kg/piece)
|
0.35
|
|||
Linear Rail Weight(kg/m)
|
2.3
|
|||
Linear Rail length
|
100mm-4000mm
|
|||
Dimensions
|
||||
Height(M)
|
30mm
|
|||
Width(W)
|
63mm
|
|||
Height(L)
|
74mm
|
|||
Dynamic load capacity (C KN)
|
13.8
|
|||
Static load capacity(C0 KN)
|
23.8
|
FAQ


FAQ
FAQ
Q1:What's the delivery time?A1:In 2~3 days after receiving the payment. Q2 :What brand is this? A2: It's THK brand. Q3: Is this the THK original? A3: Yes, it is.
